Project Description
A prototyping workflow that helps members move from an idea to a physical part. It supports robotics, embedded systems and product design projects.
Supervisor: NEXUS Project Team
Materials
Hardware / Material
- PLA filament
- 3D printer
- Caliper
- CAD model
- Slicing software
- Prototype screws
Technologies
Technologies Used
SolidWorksSTL exportCura slicingLayer height tuningPrint bed calibration
Tutorial
Build Steps
- Sketch the mechanical need and define constraints.
- Model the part in CAD with exact dimensions.
- Export the design as STL.
- Prepare print settings in the slicer.
- Print and test the part.
- Iterate based on fit, strength and usability.
Images
Project Gallery
Code
Code / Repository Notes
// Example design note
// Tolerance for printed holes: add 0.2mm to 0.4mm depending on printer calibration.
